Dynamic Rotor Balancing Service

Dynamic Rotor Balancing Service

Balancing Specifications

  • Dynamic balancing is achieved by rotating parts quickly and then measuring the imbalance using electronic equipment.  The imbalance calculated can then be added or subtracted from the component until the vibration of the parts is reduced to the required ISO tolerance.  Our balancer has the capability for components with weight up to 1100 kg and a length of 4675mm.
  • Drive shaft balancing of up to 4675mm.
  • Fans up to 1000mm.
  • Power take off shafts (PTO) of up 4675mm.
  • Industrial drive line shafts.
  • Crankshafts.

Technical information

  • Maximum weight symmetric rotor 1100kg
  • Maximum diameter of rotor 1100mm
  • Diameter of rotor journals 4675mm
  • Length up to 4675mm
£360.00 GBP
£360.00 GBP
Tax included.

Important Ordering Information

Please note:we do not take orders on the website for Europe, The Channel Islands, Isle of Man or Ireland. If you wish to place an order to one of these locations, please give us a call on+44 (0)1228 712121to discuss shipping options

Full Dynamic Rotor Balancing Service details.

Precision Balancing to ISO Standards

We provide precision dynamic balancing services in Cumbria to ISO 21940 standards. Our service suits a wide range of components, including rotors, prop shafts, fans, and high-speed drums. As a result, your machinery runs smoother, lasts longer, and performs more efficiently.

Component Sizes and Capacities

Our dynamic balancing equipment handles large and heavy components with ease. We can balance items weighing up to 1,100 kg, with a maximum length of 4,750 mm and a diameter of 1,250 mm. Because of this capability, we support both agricultural and industrial applications.

For best results, we strongly recommend balancing components with flails or blades installed. This approach ensures accurate results under real working conditions.

Advice and Quotations

If you require guidance or a quotation, please contact our team. We are always happy to offer clear advice and competitive estimates.
